SCR 400(S) / 500(S)


MIG / MAG Welding Power Sources for Shipyards

SCR 400(S)/500(S) are heavy-duty welding equipment specially designed to meet the requirements of welding applications in the shipyards and is suitable for semiautomatic and mechanized welding applications on account of its excellent arc stability and smooth welding. Servo wire feeder with remote pendant and PSF range of torches enhances the performance.

INPUT

OUTPUT   PROCESS


SAILENT FEATURES


  • Tough machine for shipyards
  • Smooth welding and minimum spatter
  • Clean tip ensures smooth arc striking
  • Selector switch for CO2 or Mixtures
  • 2 / 4 stroke selection
  • Crater control facility
  • Lightweight Servo feeder
  • Wire feeder interconnection possible up to 50m
  • Suitable for Solid / Al / FC wire
  • Available with 4-roll drive option

Specially engineered torch and components for outstanding welding performance and longer operational life


MIG Torches


  • PSF range of proven torches
  • Available in 3 or 4.5m lengths
  • Ergonomically designed
  • Light weight, durable and long life
Technical Data SCR 400(S) SCR 500(S)
Power Source
Mains supply, Ph x V, Hz 3 x 415, 50 3 x 415, 50
Open circuit voltage, V DC (Max) 55 59
Welding current range, A 60 – 400 60 – 500
Welding current at 60% duty cycle, A 400 400 (500 @60%)
Welding current at 100% duty cycle, A 400 400(5500 @100%)
Remote Control for Welding Voltage/Current Yes Yes
Insulation class H H
Dimensions, l x w x h, mm 710 x 435 x 760 710 x 435 x 760
Weight, Kg 150 154
Wire Feeder SERVO-I SERVO-II
Drive system DC motor DC motor
Speed control Stepless Stepless
Feed mechanism Standard 2-roll quick changeover type
Optional 4-roll quick changeover type		 Standard 2-roll quick changeover type
Optional 4-roll quick changeover type
Wire feed speed, m/min 1 – 22 1 – 22
Wire diameter, mm 0.8 – 1.6 0.8 – 1.6
Wire type MS / Al / FC MS / Al / FC
Weight, Kg 9 9
Ordering Information
Power Source 4650683000 4650683000
Wire Feeder, 5m, 2-Roll 4650687010 4650687610
Wire Feeder, 5m, 4-Roll 4650687000 4650687000
MIG Torch, PSF 405 3m 4650692920 4650692922
MIG Torch, PSF 405 4.5m 4650692921 4650692923
Regulator Dura CO2 4650193002 4650193002
Regulator ICO 32B 4330193100 4330193100
CO2 Heater 110V 1651689045 1651689045
Regulator Dura Argon 4650193001 4650193001
Regulator IAR 52B 4330196320 4330196320
