EDW 350 / 400 / 500
The Best Choice for onsite Application
*Silenced Canopy - Noise level<75dB at 1mtr from the Equipment. CPCB approved.
Engine Driven welder with built-in Auxiliary Power Unit (both 1phase and 3 phases).
Performance
- Reliable water cooled engine
- Mechanically operated Governor from MICO BOSCH with excellent sensitivity
- Heavy duty water cooled diesel engine with turbo for good fuel efficiency
- Large fuel tank capacity ensures long hours of operation without refueling
- Capable of MMA welding with up to 4.0/5.0 mm electrodes continually with long lead using EDW 350/400
- Capable of doing Pipe welding with Cellulosic Electrodes
- Class 'H' Insulation ensures longer operational life and for most rigorous applications
- Precisely designed smoothening Reactor facilitates almost Ripple Free Output ensuring minimum spatter during welding
- Auxiliary power outlets with heavy duty industrial plug and socket with protective shroud. Connection provided through MCB of suitable rating
| Technical Data | EDW 350 | EDW 400/500 |
| Engine | ||
| Type | 3305GM | S3.8G4 |
| Make | Mahindra & Mahindra | Cummins |
| No. of cylinders | 3 | 4 |
| Type of cooling | Water | Water |
| Starter | 12V Lucas | 12V Lucas |
| Battery capacity, Ah | 75 | 120 |
| Governor | Mechanical | Mechanical |
| Power at 1500 rpm, BHP | 30 | 58 |
| Fuel | Diesel | Diesel |
| Fuel tank volume, ltr | 75 | 80 |
| Fuel consumption, ltr/hr | 3.2 | 4.5 |
| Welding Output | ||
| Open circuit voltage, VDC | 90 | 90 |
| Welding current range, A | 10 - 350 | 10 - 400 |
| Output at 60% duty cycle, A | 300 | 400 |
| Electrode type | All including cellulosic | All including cellulosic |
| Electrode size, mm | 4.0 / continuous | 5.0 / continuous |
| Auxiliary Output | ||
| 3Ph supply, kVA, V/Ph, Hz | 7.5, 415 / 3, 50 | 10, 415 / 3, 50 |
| 1Ph supply, kVA, V/Ph, Hz | 2.5, 230 / 1, 50 | 5, 230 / 1, 50 |
| Size | ||
| Dimensions, l x w x h, mm | 2600 x 1030 x 1800 | 2900 x 1400 x 2010 |
| Weight approximate, Kg | 900 | 1250 |
| Undercarriage with tow bar | 2 wheels as standard | 2 wheels as standard |
| Noise Level | ||
| DB at 1 m distance | 75 | 75 |
| Compliance | CPCB | CPCB |
Click here to view manual of EDW 350 / 400 / 500 in PDF format
