Flexible Heavy Duty Manual Plasma Cutting

For all types cutting within production, repair, maintenance and assembly. Use on all electrically conductive materials, e.g. mild steels, aluminium and "stainless steels".

This rugged, easy to use, power efficient unit, offers excellent cutting properties. Runs off your mains supply together with compressed air or Nitrogen.

The basic guide kit for circles of 45 to 710 mm diameter. Centre fixed with pin

PowerCut T package comprise of power source & torch (Torch wrap kit is optional extra)

Performance

• Compact portable design - Goes to the job, easily moved about
• Delivers big machine cutting power in a rugged, lightweight package
• Arrives ready to cut, with torch connected and front-end parts in place, for the ultimate in operator convenience
• Trigger lock-in for long-cut operator comfort
• Adjustable output - Tailor the current to the material being cut
• Tolerates poor power lines

Long Life & Reliability

• Rugged design - PowerCutT 's external housing design is durable, damage-resistant, corrosion-resistant and weather resistant, while remaining lightweight for portability
• Suspended electronics - Sensitive internal electronics are suspended from the aluminium frame, insulating them from shock and vibration
• Sealed switches - Silicone-sealed switches are immune to corrosion, as well as dust and dirt infiltration
• Automatic fan control - The cooling fan is automatically controlled to run only when necessary, to conserve energy and reduce ingested dust and dirt
• Built-in power line conditioner - Protects against damage from power line noise and spikes, even with poor - quality power

The PT-31XL PC Manual Cutting Torch

• Compact simple torch - Easy access, little maintenance
• Durable torch cable prevents snagging on fixtures and materials
• Patented XT nozzles - Extended shape gives good visibility as well as good consumable life
• Drag or standoff cutting - Easy operation with little or no training
• Template following feature - Easily duplicates curves or straight lines

Easy to Use

• Tool-less quick disconnect torch - Edisconnects from the machine without the use of wrenches or special tools. It is easy to disconnect the torch for storage, repairs or replacement
• Digital readout display - Easy to read and shows the exact pressure or amperage, so you can operate with confidence. The display also shows help codes to assist in troubleshooting minor errors, reducing downtime
• Trigger lock function permits releasing switch for long cuts
• Torch wrap and wear parts kit holder - This optional item lets you neatly wind up torch and cables for convenient storage

• Powerful performance - PowerCutT offers the highest speeds and thickness capabilities, as well as high duty cycle ratings, for outstanding productivity and performance
• Powerful economy - Through a combination of long part life, high speeds and simple torch design, the PowerCutT offers the lowest cost per cut meter of any machine in its price class
• Powerful durability - This robust cutting unit stands up to rugged treatment and outdoor use, plus cuts up to 16 mm metal with ease
• Powerful ease of operation - With features such as the tool-less quick disconnect torch and a digital readout display, the PowerCutT is easy to set and operate, increasing productivity and reducing downtime

Technical Data	PC-650
Mains voltage, V/Ph Hz +/ -15%,	1x230, 50 (400V optional)
Fuse (slow), A	32
Mains cable, Ø mm2	6
Setting Range	10-40A
Permitted load at 60% duty cycle, A/V 100% duty cycle, A/V	30/120 22/120
Power factor at maximum current	0,76
Efficiency at maximum current, %	0,85
Air requirements l/min / bars	118 / 5.2
Dimensions lxwxh, mm (w/o torch handle & torch wrap)	483x318x419
Weight, kg	24
Recommended generator power	kW 10
Manual cut capacity Cuts, mm	15.9
Severs, mm	19
Ordering Information
Description	Code
PowerCutT 650 230V package	16F0316030
Optional Accessories
Torch Guide Kit Deluxe (44.5 to 106 cm Radius)	16F1102001
Torch Guide Kit Basic (44.5 to 71 cm Radius)	16F1109001
PT-31XL PC Torch 15.2m	16F1120001
