From the Inventors of Plasma Cutting

INPUT
OUTPUT				PROCESS

LPH is suitable for Al, SS and also for Carbon Steel

• Faster and economical on Al, SS, Carbon steel below 12mm
• Cutting starts from 0.1mm onwards unlike 6mm of flame cutting
• Very safe and convenient on any application
• No distortion even on sheets below 6mm
• Savings on storage and maintenance of gases
• Better quality of cuts
• Easy to adapt and lesser skill requirements
• No naked flames
• Circle and profile cutting accessories
• Light weight torches makes cutting effortless

Always insist on genuine accessories and parts for best performance

Quality Accessories for the Quality Welder

ESAB offers a wide range of accessories. The complete range, along with product information, is available at our local web-sites, look at www.esab.com or contact your local ESAB dealer.

Technical Data	LPH 35	LPH 50	LPH 80	LPH 120
Mainsupply V/Hz	3x415/50	3x415/50	3x415/50	3x415/50
Fuse slow A	16	25	32	50
Rated power KVA	11	16.5	20	30
Max output At 35% duty cycle A At 60% duty cycle A At 100% duty cycle A	35 20	50 30	80 60 & 40	120 90 & 60
Open circuit voltage V	295	320	310	310
Pressure bar	3.5-7	4.5-7	4.5-7	4.9-7
AirSupply L/min	130	118	118 1	86-236
Cooling air L/min	-	-	-	132-1 70
Cutting capacity, Fe mm	8/12*	12/15*	25/35*	35/45*
Enclosure class	IP 23	IP 23	IP 23	IP 23
Weight kg	52	89	131	167
Dimensions LxWxH mm	610x255x515	680x325x515	760x390x845	760x390x845
Ordering information	46F0303035	46F0301 050	46F0301 080	46F0304120
