Auto K 400 / 600


Thyristorised Power Sources for MIG / MAG Welding Auto K 400 / 600

is one of the proven equipments for semi-automatic and mechanized welding applications on account of its excellent arc stability and smooth welding. Servo wire feeder with remote pendant and PSF range of torches enhances the performance.

INPUT

OUTPUT   PROCESS


SAILENT FEATURES


  • Digital V/A Meters
  • Fully thyristorised hex phase control
  • Stick out control
  • Crater control
  • Fresh Tip Treatment (FTT) eliminates globule formation at the wire tip during weld stop
  • Quick Arc Start
  • Gas pre-flow setting
  • Choice of CO2or Argon Mix
  • Self Hold ON function
  • Servo feeder with quick changeover mechanism
  • 4 roll drive option
  • Suitable for solid and flux cored wires
  • Separable remote control

Specially engineered torch and components for outstanding welding performance and longer operational life


MIG Torches


  • PSF range of proven torches
  • Available in 3 or 4.5m lengths
  • Ergonomically designed
  • Light weight, durable and long life
Technical Data Auto K 400 Auto K 600
Power Source
Mains supply, Ph x V, Hz 3 x 415, 50 3 x 415, 50
Open circuit voltage, V DC (Max) 55 68
Welding current range, A 60 – 400 60 – 600
Welding current at 60% duty cycle, A 400 600
Welding current at 100% duty cycle, A 310 470
Type of Welding Voltage/Current Regulator YES YES
Insulation class H H
Type of cooling Forced Air Forced Air
Dimensions, l x w x h, mm 675 x 350 x 690 675 x 455 x 850
Weight, Kg 122 160
Wire Feeder Servo-I Servo-II
Drive system DC motor DC motor
Speed control Stepless Stepless
Feed mechanism 2 Roll (optional 4 roll) quick changeover type
Wire feed speed, m/min 1 – 16 1 –16
Wire diameter, mm 0.8 – 1.2 0.8 – 1.6
Wire type MS / Al / FC MS / Al / FC
Weight, Kg 7 9
Ordering Information Auto K 400 Servo – I Auto K 600 Servo – II
Power Source 4650685000 4650684000
Wire Feeder, 5m, 2-Roll 4650687010 4650687610
Wire Feeder, 5m, 4-Roll 4650687000 4650687600
MIG Torch, PSF 405 3m 4650692920 -
MIG Torch, PSF 405 4.5m 4650692921 -
MIG Torch, PSF 505 3m - 4650692922
MIG Torch, PSF 505 4.5m - 4650692923
Regulator Dura CO2 4650193002 4650193002
Regulator ICO 32B 4330193100 4330193100
CO2 Heater 110V 1651689045 1651689045
Regulator Dura Argon 4650193001 4650193001
Regulator IAR 52B 4330196320 4330196320
Servo – I has 0.8 / 1.2 mm and Servo – II has 1.2 / 1.6 mm rollers along with 5mtr interconnection as standard, other lengths o interconnection optional.
Click here to view manual of Auto K 400/600 in PDF format (470 KB)
